The Marathoner of Industrial Power: AIRERA 30kW Belt-Driven Air-Cooled Oil-Injected Screw Compressor
The AIRERA 30kW Series seamlessly integrates advanced air-cooling technology with high-precision belt drive systems, specifically engineered for factory environments that demand consistent stability and effortless maintenance. By leveraging cutting-edge oil-injection cooling, the unit maintains optimal internal temperatures even under extreme workloads, ensuring a relentless power output while significantly reducing long-term wear and tear costs. As a flagship of the AIRERA lineup, it combines a rugged mechanical structure with superior energy efficiency to deliver a 24/7 uninterrupted supply of clean compressed air, serving as the reliable industrial heart that drives your production line’s growth and efficiency.
Advantages of AGFD Oil-Inject Air Screw Compressor:
Technical Specifications - 30KW Air Cooling Compressor
30KW Air Cooling Compressor Parameters
| ITEM |
UNIT |
MODEL AGFD-30 |
| Free air delivery |
m³/min |
5-3.25 |
| Max. working pressure |
MPa |
0.8-1.5 |
| Compressor type |
|
Oil inject screw compressor |
| Cooling type |
|
Air cooling |
| Driven type |
|
Belt driven |
| Inlet status - Temperature |
℃ |
≤55 |
| Inlet status - Pressure |
MPa |
Atmospheric pressure |
| Inlet status - Relative humidity |
|
≤90% |
| Noise Level |
dB(A) |
≤72 |
| Residual oil content |
ppm |
≤1 |
| Drive rotor speed |
rpm |
4030~2950 |
| Compressed air outlet temperature |
℃ |
Ambient temperature＋10 |
| Cooling air flow |
m³/hr |
9200 |
| Control mode |
|
Intelligent controller |
| Safety valve set pressure |
MPa |
0.88 ~ 1.6 |
| Lubricating water volume |
L |
30 |
| Compressed air outlet connection |
|
G1 |
| Dimension - L |
mm |
1200 |
| Dimension - W |
mm |
950 |
| Dimension - H |
mm |
1300 |
| Net Weight |
kg |
680 |
| Motor - Model |
|
Y2180L2-2 |
| Motor - Speed |
rpm |
2950 |
| Motor - Rated Power |
KW |
30 |
| Motor - Service factor |
|
1.2 |
| Motor - Protection type |
|
IP55 |
| Motor - Efficiency |
|
IE3 |
| Motor - Startup mode |
|
ʏ-Δ starting |
| Motor - Voltage |
V |
380(Special on request) |
| Motor - Frequency |
Hz |
50(Special on request) |
| Motor - Rated current |
A |
56.9 |
| Motor - Weight of motor |
kg |
232 |
AIRERA 30kW Screw Air Compressor: Frequently Asked Questions (FAQ)
How does a 20-30% improvement in cooling performance benefit my production?
Heat is the enemy of efficiency. The redesigned AIRERA cooling system increases thermal dissipation by up to 30% compared to legacy models. This ensures the unit maintains an optimal constant temperature even in high-ambient summer conditions or poorly ventilated workshops, preventing high-temperature trips and protecting the lubricating oil from premature emulsification and degradation.
Is the advanced smart color touch control system difficult to operate?
On the contrary, it is designed for "Simplified Operation with Professional Management." The intuitive full-color interface provides real-time visualization of pressure, temperature, and run-time data. With built-in smart alarms and automated maintenance reminders, it allows even non-technical staff to manage the equipment effectively, drastically reducing labor management costs.
How much can I save with the IE3 high-efficiency motor and 1.2 Service Factor (SF)?
Our motors improve efficiency by approximately 15%. With an SF of 1.2 for superior overload capacity and an IP55 rating for dust/water protection, these motors maintain peak performance in harsh industrial environments. Based on 8,000 annual operating hours, the electricity savings alone can often cover your entire annual maintenance budget—true "Green Production" in action.
